Edge
Features
- 100% High Quality Copper Winding
- More Than 60% Saving on Electricity
- State-of-the-art BLDC Technology
- High Grad CRNO Lamination
- Anti Dust Coating
Application
• Bedrooms • Classrooms • Libraries • Hospitals • Offices
Color Options
Black
Black
Metallic Brown
Metallic Brown
White
White
Black & Blue
Black & Blue
Black & Orange
Black & Orange
Black & Indigo
Black & Indigo
Black & Maroon
Black & Maroon
Product Specifications
Available Sweep
| Edge Wooden | Sweep(mm) | No. Of Blade | Watt | Current | Input Voltage | RPM | Air Delivery |
|---|---|---|---|---|---|---|---|
| 12V | 1200 | 3 | 32 | 2.7 | 9V-20V DC | 375 | 240 CMM |
| 1200 | 4 | 35 | 3 | 9V-20V DC | 350 | 260 CMM | |
| 1050 | 3 | 30 | 2.5 | 9V-20V DC | 450 | 210 CMM | |
| 900 | 3 | 28 | 2.4 | 9V-20V DC | 550 | 190 CMM | |
| 24V | 1200 | 3 | 30 | 1.25 | 20V-30V DC | 375 | 240 CMM |
| 1200 | 4 | 35 | 1.4 | 20V-30V DC | 350 | 260 CMM | |
| 1050 | 3 | 28 | 1.1 | 20V-30 DC | 450 | 210 CMM | |
| 900 | 3 | 28 | 1.1 | 20V-30V DC | 550 | 190 CMM |
Actual Products may vary in color, design, description and color combination etc. although every export has been made to ensure accuracy in the compilation of the technical detail within this publication, specification and performance date are constantly changing.
Remote Control & Operations
- 1. True On/Off Fan
- 2. Speed Switches 1 to 5
Operation Theory
- 12V DC BLDC Ceiling Fan With Remote Control
- High Speed 375 RPM, 32 Watt
- Use 2.5 square mm wire in Dc side for better Performance
- Directly Runs on 12v Solar Panel (60w-100w)
- Operating Voltage range is 10V-19V DC
Technical Specifications
Features
State Of Art BLDC technology
Lowest Heat Emission
Sleep Mode that reduces the speed after set hours and saves energy
Blocked Blade, Over Voltage, Under Voltage And Over Current Protection
Triple Invertor’s Backup Hours in Invertor fan
No humming Noise
Highest service Value (Air Delivery/Watt)
Full Speed Even At Low Voltage & Power Fluctuations
